ShoreStation Controller 6.0 Upgrade Kit for Freestanding Lifts (HA0364)

Upgrade your existing ShoreStation® hydraulic freestanding lift to the newest Controller 6.0 smart control system. The HA0364 Lift Control Upgrade Kit modernizes older lifts by replacing outdated key switches, toggle switches, and blue remotes with an advanced digital keypad, long-range wireless remote, and app-enabled control. This upgrade delivers enhanced safety, improved reliability, and full compatibility with the ShoreStation® smartphone app for monitoring and control.

What the HA0364 Upgrade Kit Does

The ShoreStation 6.0 system is a ground-up redesign of the previous control electronics. It unifies control of your lift, optional ShoreScreen™, and canopy lights into a single keypad, remote, and Bluetooth app platform, giving your existing lift the same control experience as current ShoreStation® models.

• Faster, more reliable electronic control
• Secure digital keypad (no physical key required)
• Long-range wireless operation (up to 300 ft in ideal conditions)
• Bluetooth connectivity through the ShoreStation® App
• Enhanced safety features like Total Lockout & Emergency Stop
• Compatibility with modern pump harnesses and accessories

What’s Included in the HA0364 Kit

The HA0364 kit includes factory ShoreStation components designed specifically for freestanding hydraulic lifts:

• Controller 6.0 Electronic Control Unit (ECU) – mounts to the pump box using existing hardware.
• ShoreStation 6.0 Keypad – replaces all old key/toggle switches with a sealed, code-locked interface.
• ShoreStation 6.0 Wireless Remote – handheld remote for lift, screen and lights (two A23 batteries, range up to 300 ft).
• New Motor Harness designed for the 6.0 system (replaces the original harness in the pump box).
• Extension harnesses & limit switch extension (used where additional reach is needed).
• Mounting hardware (reuses many existing fasteners; ShoreStation recommends having extra hardware available at install).

If your lift is equipped with a ShoreScreen™, additional parts may be required (see the ShoreScreen compatibility section below).

Key Features of the ShoreStation Controller 6.0

Three Ways to Operate Your Lift

• On-board Keypad – secure, code-based access and full control at the dock.
• Wireless Remote – long-range handheld control that operates independent from the keypad mode.
• ShoreStation® App – Bluetooth connection from your smartphone for convenient, close-range operation.

Keypad Features

• Controls up to three functions: Lift, ShoreScreen, and Canopy Lights (Modes 1–3).
• LED battery level indicator: green/red states indicate approximate remaining capacity.
• Operating states:
  • Wireless State – lift locked at keypad, remote & app still active.
  • Unlocked State – full keypad control after entering 4-digit code.
  • Total Lock State – complete lockout; no device can run the lift.
• Customizable 4-digit security code (replaces universal key).
• Automatic re-lock after 5 minutes of inactivity.
• Tilt adjustment function (for permanent lift models that support it).

Wireless Remote Features

• Dedicated mode button to toggle between Lift, Screen, and Light modes.
• Battery level indication with 1–4 LEDs when opened.
• Light/Tilt-Adjust button for canopy lights or lift leveling (per lift configuration).
• Automatic sleep when the lid is closed to preserve battery life.

ShoreStation App Features

• Up/Down control for the lift and ShoreScreen™ from your phone.
• On/Off control for canopy lights plus configurable auto-shutoff timer (5, 15, or 30 minutes).
• Live battery voltage and daily voltage history that can act as a quick “load test”.
• Enable/disable specific equipment: Lift, ShoreScreen, Lights, Lift Adjust, PWC Lift.
• System information view with hardware/firmware details and over-the-air firmware updates.

Compatibility

Lifts

The HA0364 upgrade kit is designed specifically for:

• ShoreStation Freestanding Hydraulic Lifts, 5,000 lb capacity and larger

It is the factory-specified 6.0 system upgrade kit for freestanding models, allowing older hydraulic lifts to use the same control platform as new 2026 Program Year lifts.

Replaces Older Components

When this new control system is installed, all previous key switches, toggle switches, and blue remotes are removed for the lift being upgraded.

ShoreScreen™ Integration (If Present)

If your freestanding lift has a ShoreScreen™, integration with Controller 6.0 may require additional kits, depending on the existing relay type:

• 3.0 style relay – typically compatible with 6.0 using the appropriate screen control kit.
• Cube relay – must be replaced; the HA0364 instructions specify that cube-style relays are not compatible with Controller 6.0 and require a relay upgrade kit.

Common accessory kits used with HA0364 include screen control and battery cable kits (e.g., HA0362/HA0363 and 5310352/5310365). Upgrade scenario charts in the product bulletin outline which kits are used for various lift and screen combinations.

Installation Overview

The HA0364 kit includes a detailed factory installation manual. Below is a high-level summary of the process; professional installation or a qualified dealer is recommended.

1. Disconnect Main Power – unplug the lift power before working on any components.
2. Remove Old Control Unit – unbolt and unplug the original controller from the pump box.
3. Remove Old Harness Wiring – disconnect main power, solenoid power, reversing coil, limit switch, and ground wires from the pump. Old antenna and indicator wiring are removed as they are no longer used.
4. Install New Harness – connect the new harness to the same locations (main power, solenoid, reversing coil, ground, and limit switch), using new ground points where specified for bottom-mounted pumps.
5. Mount New Controller 6.0 Unit – reuse existing pump box bolts to secure the new controller in place.
6. Test Operation – connect the keypad and temporarily connect power to verify lift and screen functions in “dockside mode” (unlocked keypad with default 1-2-3-4 code).
7. Route Extension Harnesses – permanently route keypad and relay extension harnesses along the canopy frame or leg, securing with zip ties and keeping all electrical connections above the water line.
8. Finalize & Close Pump Box – neat wire management, reconnect main battery power and close the pump box lid.

Why Upgrade to Controller 6.0?

Modern Smart Controls

The 6.0 system brings your older lift up to the latest control standard with keypad, remote and app control working together. You can monitor battery voltage history, enable specific equipment, and receive firmware improvements over time.

Safer & More Secure

Code-based access replaces physical keys, while Total Lockout mode and the Emergency Stop function give you quick, reliable ways to prevent or stop lift movement for safety.

Improved Reliability & Clean Wiring

With a new harness and consolidated controller, the lift’s electrical system is simplified, removing multiple boxes, switches and legacy remotes. This reduces potential failure points and provides a cleaner, more serviceable installation.

Future-Friendly

Over-the-air firmware updates through the ShoreStation® App help ensure your control system stays current as improvements are released, extending the useful life of your lift’s electronics.

Specifications

Need Help Confirming Compatibility?

Not sure which control kit or relay parts you need? Email or text us photos of your:

• Pump box (inside and outside)
• Existing controller / key switch or toggle box
• Any ShoreScreen™ relays mounted to the canopy frame

We’ll review your setup and confirm the correct ShoreStation® parts before you order.

Ready to Upgrade?

The ShoreStation Controller 6.0 upgrade kit (HA0364) is the factory-approved way to modernize your freestanding hydraulic lift, giving you a safer, smarter and more convenient way to raise and lower your boat for years to come.
