NEW Canopy Covers
SHIP FREE

CraftLander 24' x 120" HighTop Frame

Manufacturer: CraftLander

Typically Ships: 15-25 Business Days

Model: CL-CF24120-hightop

Item Type: Lift - Canopy Frame

Designed to Fit: CraftLander

Choose Leg Option
Options
QTY:
Base Model Regular Price: $1,945.00
Configured Price: $1,945.00
OVERVIEW

CRAFTLANDER 24' X 120" HIGH TOP ALUMINUM CANOPY FRAME

This is a 24' x 120" High Top CraftLander Aluminum Canopy Frame and can be used with any Craftlander lift with a 120" inside width and comes with the complete canopy frame and standard 48" canopy legs.

If your boat has a tower or tall canopy as part of its design you should seriously consider the 'tower end bow' canopy option.  This specially designed end bow for the Craftlander high-top canopy frame is welded specifically to allow watercraft with large towers like wakeboard boats, boats with ski towers, and pontoon boats to enter and exit the lift with ease.  The tower end bow's lower frame tube has been raised and welded well above the rest of the canopy frames lower frame tube.  This gives you much more room coming in and out of the lift.  Since your canopy legs don't have to be raised as high to enter or exit you can tuck your towered boat up into the high-top frame even more for far superior coverage when the boat is being stored.

If you order a new canopy cover to match the frame with a 'tower end' your cover will come with 'zippered ends'.  This means the rear face of the cover at the entrance to the lift will have two verticle zippers to 'zip-up' the rear panel when entering and exiting the lift.  In conjunction with the tower end bow, this solves most height issues when storing your towered watercraft while maximizing boat coverage when the boat is being stored on the lift.

If the height of the frame is still an issue then we then recommend upgrading to 72" XL canopy legs which will give you another 24" of height with which to get the lift in and out of.



KEY FEATURES

  • Fits Craftlander Lifts with 120" inside width
  • Aluminum Construction
  • 'Tower End' Optional
  • 72" XL Canopy Leg Optional



INCLUDES

  • Side Frames
  • Hoop Bundle
  • Canopy Support Braces
  • Hardware Box
  • 48" Standard Leg Set (can upgrade to 72" XL canopy legs)


KIT DOES NOT INCLUDE CANOPY COVER. Covers are available in several materials and colors designed to fit this frame and can be found under the "available accessories" area of this web page.



ADDITIONAL INFORMATION

  • When the carrier picks up the items then tracking information will be sent via email.
  • For estimated shipping charges add the items to your cart and enter your zip code into the shipping calculator on the cart page.
SPECIFICATIONS
Manufacturer: CraftLander
SKU: CL-CF24120-hightop
Base Group
Product MPN: CL-CF24120-hightop
Shipping
Typically Ships: 15-25 Business Days
Shipping Method: LTL Freight
Frame Specs
Adjustable Leg Size: 48
Frame Material: Aluminum
Mount Style: Lift Column Mount
Fasteners: Zinc Plated Steel
Canopy Width: 120
Canopy Length: 24
Canopy Support Legs: Included
General
Model: CL-CF24120-hightop
Item Type: Lift - Canopy Frame
Designed to Fit: CraftLander
Warranty
Restocking Fee: Yes
Cover Specs
Attaching Hardware: Included
MFG Info
Product Manual: View Product Manual
Documents
