STANDARD 10' VINYL / ALUMINUM HULL BUNK KIT – This configuration is well suited for single hull designs, including flat bottom, round bottom, and shallow-V hull designs. The Vinyl/Aluminum Bunk includes two individual aluminum extrusion bunk rails covered with a non-abrasive vinyl. These bunks are maintenance-free and do not trap lake sediment like older-style carpeted lumber bunks. The brackets allow the bunks to be adjusted across the cradle, customizing it to fit your boat.

SKI 10' VINYL / ALUMINUM HULL BUNK KIT – This configuration is well suited for single hull designs and is similar to the Standard bunk option above. However, the Ski version offers additional height clearance over the cradle beam so that the tracking skegs (fins located on the underside of ski and some wakeboard boats) clear the cradle on entering the lift. This bunk configuration is well suited for Deep-V and Ski / Wake style watercraft. The Vinyl/Aluminum Bunk includes two individual aluminum extrusion bunk rails covered with a non-abrasive vinyl. These Bunks are maintenance-free and do not trap lake sediment like older-style carpeted lumber bunks.

PONTOON / TRITOON RACK – This configuration is used with Pontoons and sometimes with Tritoon boat designs. When set up correctly, this is the easiest way to park a pontoon on a vertical lift. The pontoon rack includes four vertical cradle-mounted aluminum assemblies. The assemblies are in pairs and 2" x 10" x 14' non-treated lumber is used to span between each pair of assemblies. This creates the support that lifts from beneath the deck of your pontoon or tritoon. The lumber is not included and must be supplied by the customer. Pontoon rack systems such as this have been widely used for a number of years due to the basic design and user-friendliness.

VINYL / ALUMINUM PONTOON SADDLE BUNK KIT - Available in 10' and 12' in length, these bunks are well suited for pontoons and tritoons. The kit includes two sets of aluminum extrusion bunk rails covered with non-abrasive vinyl and two sets of saddle brackets that allow a pair of bunks to span between the lift I-beams and fit the round pontoon perfectly. We add an additional set for tritoons as long as all three toons are the same size. The Vinyl/Aluminum Bunks are maintenance-free and do not trap lake sediment like older-style carpeted lumber bunks. When installed, each set of bunks are located on the exterior of the cradle and are designed to support the underside of toons.

TRITOON VINYL/ALUMINUM TRIPLE BUNK KIT - This configuration is well suited for Tritoons. This kit includes three 12' bunk sets and also includes additional brackets for Tritoons with oversized center toons. The Vinyl/Aluminum bunks are maintenance-free and do not trap lake sediment like older style carpeted lumber bunks. When installed this system allows for the support of three toons.

SEADOO SWITCH HULL BUNK KIT - The kit features two pairs of 12-foot bunks. One pair cradles the central pontoon, while the other pair maintains equilibrium on the outer sections, ensuring that your boat remains securely balanced on the lifts cradle. This configuration guarantees consistent and level support for your boat each time it is parked.

PONTOON / TRITOON VINYL GUIDES - This aluminum and vinyl horizontal guide system makes contact with the toons themselves in the perfect location to keep the boat centered over the cradle and bunks. They are adjustable across the beam allowing them to be customized to the width of the boat. Easy to use and easy to insatll.

15'  HEAVY DUTY VERTICAL LOAD GUIDES - These 15' HD Vertical Load Guides are built for superior boat protection and stability. Featuring eight rigid aluminum uprights with durable PVC covers, each upright can be positioned anywhere along the side rail for a custom fit. Designed to provide strategic contact at impact-resistant points, vertical load guides help safeguard your boat in rough waters and high-wind conditions.

FULL LENGTH CARPETED SIDE GUIDES - These guides consist of aluminum upright brackets that securely attach to the I-beam of the hoist. These brackets support carpeted lumber rails reinforced with steel backer plates, extending the full length of the hoist on both interior sides. The carpeted rails serve as centering guides, ensuring safe and precise positioning on the hoist While these guides are compatible with pontoons and tritoons, T.A.P. fins may cause damage by cutting or tearing the carpet. For optimal performance and durability, we recommend the Pontoon/Tritoon Vinyl Guides as the preferred option for horizontal guiding.

STANDARD LEG - the standard leg option includes 54" legs (overall length) that provide 38" of usable height. The leg uses a large foot pad for stability and hitch pins for height adjustment. This telescoping design allows for proper installation in a variety of water depths up to 7 feet deep.

DEEP WATER LEGS - the longer adjustable 72" leg extensions provide 53" of usable height. These are used for deeper water and are a much heavier duty extrusion. The leg uses a large foot pad for stability and hitch pins for height adjustment. This telescoping design allows for proper installation in a variety of water depths up to 8.5 feet deep.

MOTOR STOP - Mounted to the stern end rack beam and assists with stopping your watercraft and prevents your boat from overrunning the lift.
