4' x 9.5' Anodized Aluminum Boardwalk Dock Section for Platform

Item Type: Dock - Freestanding

Material: Aluminum

Typically Ships: 10-15 Business Days

QTY:
Our Regular Price: $799.00
On Sale: $699.00
OVERVIEW

4' x 9.5' ANODIZED ALUMINUM BOARDWALK DOCK PLATFORM SECTION



When creating platforms where the sections are installed side by side, we recommend incorporating this 9.5' long dock section. This allows the platform and straight-run sections to line up so that the support lines up correctly with the sections. You can see this in the drawing below. This keeps you from needing to add an additional support before the platform and makes the installation a little easier. It also provides a cleaner, nicer look and can be used with Traditional or UDS dock supports.



KEY FEATURES

  • 4' x 9.5' Section Size
  • Used for Side By Side Platforms
  • Section Weighs Approximately 92 lbs
  • Comfortable on Bare Feet
  • Fully Anodized
  • Cool to the Touch
  • Welded Aluminum Under Deck Support
  • Lightweight...Easier to Install
  • Made in Michigan



Our Anodized Aluminum Dock Sections are economical, lightweight and comfortable to walk on. These sections use aluminum decking designed to resemble a 5/4" deck board and 4" F-channel side stringers. They also include two underside stringers that better support the decking than other sections built with a single underside stringer. The dock sections are maintenance-free and the anodized aluminum finish keeps them cool to the touch, even in direct sunlight.

These aluminum dock sections provide a sleek look with durable build quality and are easy to clean and maintain.



WHAT DOES ANODIZING MEAN?

Anodizing is an electrolytic passivation process used to increase the thickness of the natural oxide layer on the surface of the aluminum. When this is done, it is like adding a clear coat to the aluminum that protects it from corrosion and discoloring. It is also the reason the dock stays cool in direct sunlight. Raw or Non-Anodized aluminum discolors over time, will transfer a black residue to skin or clothes and can get extremely hot in direct sunlight.



DOCK SUPPORT AND LAYOUT

In most cases, each section requires a single dock support and can use a Traditional H-Frame Support OR a UDS (Under Dock Support)...which provides a nice, clean look with no posts above the dock surface. Sections can also be installed side by side or side to end to create platforms and seating areas. We offer UDS and beam-style supports for platforms and can go as wide as you need.

If you are having issues determining a dock layout or have questions, feel free to contact us and we can provide some assistance.



ADDITIONAL INFORMATION?

  • This product ships out common carrier freight. For complete dock systems, contact us for a custom shipping quote.
  • This product can be ordered and picked up at our location.
  • Local (West Michigan) delivery and installation are also available.
SPECIFICATIONS
SKU: BLD-495-CF4E-ANO
Quick Info
Section Width: 4'
Section Length: 10'
Fasteners: Zinc Plated Steel
Item Type: Dock - Freestanding
Material: Aluminum
Part Type: Dock Section
Frame Spec
Frame Material: Aluminum
Decking Spec
Decking Material: Aluminum - Anodized
Support Spec
Includes Legs: No
Dimensions
Side Stringer Size: 4"
Shipping
Typically Ships: 10-15 Business Days
Shipping Method: LTL Freight , Pickup
Warranty
Warranty: 1 Year Limited
