Max Dock LochDock Gen 3 Aluminum Dock Sections with Sure-Step Vinyl Tread Decking
Product Overview
Upgrade your lakefront with the LochDock Gen 3 by Max Dock—engineered for superior strength, stability, and ease of installation. Inspired by features found in Max's commercial-grade systems, the LD3 dock sections feature a 6.5" tall proprietary stringer design with internal and external accessory tracks, a 5.25" internally jig-welded substructure, and Max’s QCS (Quick Connect System) for effortless modular setup. Combined with Sure-Step™ vinyl tread decking, LochDock Gen 3 delivers performance, safety, and a clean, modern look for any lakefront property.
Key Features
- Next-Gen Structural Strength: 6.5" tall aluminum stringers with internal welded leg pockets and dual accessory tracks. The 5.25” substructure exceeds most competitors' dock frame height for unmatched stiffness and walkability.
- Sure-Step Decking Panels: Eco-friendly, non-slip polypropylene with open-web design to reduce wave lift. Available in Gray, Tan, and White.
- Quick Connect System (QCS): Welded male and female ends with locking pins allow tool-free end-to-end, side-by-side, or angled connections.
- Easy Accessory Integration: Dual-track stringer system accepts standard 3/8” stainless bolts and nuts for fast mounting of bumpers, cleats, and more.
- Premium Leg Kits: Choose from Shallow or Deep Water Kits with tool-free adjustable legs, gussets, and aluminum foot pads for stability in any depth.
Section Sizes & Models
4' x 8' LochDock LD3 Sections
- Gray: LDDSO-408-GS-GY
- Tan: LDDSO-408-GS-TN
- White: LDDSO-408-GS-WE
- Weight: 103 lbs
- Dimensions: 96.25" x 48.25"
4' x 12' LochDock LD3 Sections
- Gray: LDDSO-412-GS-GY
- Tan: LDDSO-412-GS-TN
- White: LDDSO-412-GS-WE
- Weight: 156 lbs
- Dimensions: 144.25" x 48.25"
Add LochDock LD3 Leg Kit Components to your section
Part #: 55-12139 – LochDock Shallow Water Leg Kit - Leg Adjustment Range: 24" - 44"
Part #: 55-12140 – LochDock Standard Leg Kit - Leg Adjustment Range: 36" - 56"
Part #: 55-12141 – LochDock Deep Water Leg Kit - Leg Adjustment Range: 48" - 98"
Each Leg Kit Includes:
- (2) Square Legs
- (4) Square Leg Gussets
- (2) Adjustable Leg Tubes
- (2) LochDock Foot Pads (7.5” x 10”)
- (2) Quad-Grip Handle Boot Collars
- (2) Diagonal Boot Gusset Clamps
- (1) Complete Leg Kit Hardware Bag
Decking Details
Sure-Step® Grated Vinyl Decking
- Slip-resistant surface (wet or dry)
- Reduces heat retention
- Moisture and insect resistant
- Open-web chevron pattern reduces wind/wave uplift
- Eco-friendly and low maintenance
Installation
Install and adjust quickly with Max’s QCS locking system and Quad-Grip leg handles. Legs telescope inside the welded pockets—no tools or exposed posts required for height adjustment. The internal leg pockets maintain a flush deck surface.
Shipping & Pickup
Available for LTL freight delivery or local pickup by appointment from our Plainwell, MI location. Contact us for a custom quote, system design, or shipping estimate.
