MAXSTAND 6' - 8' "STANDARD" ADJUSTABLE HIDDEN UNDER-DOCK SUPPORT WITH A-FRAME STANCE

The 6'' to 8'' Adjustable Under Dock Support with A-Frame Stance is hidden from the top of the dock and provides great stability.  The deeper the water, the wider the stance which creates a more stable dock in comparison to traditional H-Frame style supports.  Under dock supports create a more aesthetically pleasing look, when installed there are no posts above the walking surface as you find with other support styles.

KEY FEATURES

• Adjustable from 6'' to 8''
• Stand end with stringer bracket and 1/2" stainless bolt & brass nut leg adjuster (2)
• 37" center cross member section (1)
• 34" 2" round extension tubes (2)
• 1/2" stainless bolt and brass nut leg adjuster (2)
• 36" Telescoping Leg post (2)  (Optional Leg Lengths available)
• 7" x 12" Angled Base Pad (2)

SUPPORT DESCRIPTION

• STRINGER BRACKETS - This is where your dockside stringer will sit and has holes to fasten the dock section to the support.
• CENTER CROSSMEMBER - This portion of the support uses the same extrusion as the Stand Ends and work as the main central support for the stand.
• EXTENSION TUBES - These tubes slide into the Center Crossmember and Stand Ends and allow for the width adjustment. A simple 1/2" stainless bolt and brass nut are used on the Center Crossmember and Stand End to tighten up the Extension Tube at a given width.
• STAND END- These are the two angled ends of your support and included a 45° brace and the Stringer Bracket. This assembly also has two 1/2" stainless bolt and brass nut Leg and Extension Tube, adjusters.
• LEG POST AND BASE PAD - Included, but not pictured.

AVAILABLE SUPPORT STYLES

ADDITIONAL INFORMATION

• Product ships via UPS
• Please contact us for supports requiring assemblies exceeding 9ft
